H type layer cage equipment

Cage and frame system

Mature design can provide a comfortable environment for chickens

So as to bring you good breeding benefits

Mature design of

Longfeng Layer Cage

Equipment

Watering System

Cone valve, double seal, 100% factory inspection, no water leakage

Square water pipe：PVC,22*22mm

Pressure regulator: reverse cleaning

Rewashing

Medicine Pressurizerdoser: special dosing device ofFrance Dosatron Brand

A V-shaped water tanktrough is arranged below the

waterdrinking line avoid water falling to the maure to prevent

wetting of chicken manure

The waterdrinking line is set on the central axis of each group of cagesin the middble of each cage lines for saving space

Real-time monitoring of chicken drinking water data, convenient for digital management

Regulator

Regulator can rewash the drinkling reverse cleaning

Clean the water pipe regularly to prevent the drinking fountain from beingnipple being blocked

Ensure the  chickens drink waterquality and quantity of chicken water

Longfeng Feeding System

The automatic feeding system consists of a silo, a feeding loading line, a feeding cart, feeding a trough, etc.

Parameter Description

Hopper Capacity: 50kg

Running speed: 8m/min

Motor: 0.75kw/line Taiwan Mingchun Motor

Material of feeding cart and running track: 275g galvanized plate

Characteristics

The Longfeng Feeding System has stable operation and uniform distribution of the feeder truck.

The special design of the trough and the  waste collection device in the front and

end of each feeding trough at the end to  avoid feed waste and save costs.

The uniquely designed uniformer

Accurately feeding adjust on the uniformer

The uniformer installed wheels and wear strips eliminate the friction between feeding trough and uniformer and

revent the corrosion layer from being worn out,so that

extend the service life of the equipment

The residual material collection device at the end can automatically collect the residual material to prevent feed waste
A trough with an inner edge prevents feed overflow when chickens eat
Through the observation hole of the hopper we can clearly observe the feed situation
The brush on the feeder can keep the trough and egg belt clean

Various capacity silos are available

86T,8T,11T,15T,16T,22T,28T10T,17T,20T

Material:275g / m² HDGgalvanized

Automatic deflation function

110mm conveying line

South Africa high-quality auger

UndertakeRelay connection of

feeding transportation linemethod,

reduce wear and increase service

life lifesapn

The driving wheel is covered with rubber as a whole to solve the problem of dung  belt deviation

The manure scraper adopts aluminum-zinc plate, which can clean manure thoroughly and has a long service life

A secondary scraper is set in the direction of rotation

Manure belt tensioning device is easy to operate

The manure belt is made of HDPP, which has good ductility

Longfeng manure removal

Advantages

The manure scraper adopts

aluminum-zinc plate, which can

clean manure thoroughly and

has a long service life

The manure belt is made of HDPP, which has good

ductility

The driving wheel is covered

with rubber as a whole to

solve the problem of belt

deviation

A secondary scraper is set in the direction of rotation

Manure belt tension device

is easy to operate

Longfeng Eggs conveyor

In order to continuously reduce the egg breaking rate, Longfeng has developed a new vertical egg picker.,

The equipment collects eggs in staggered time, Eeach layertier of eggs has a fixed egg tray to ensure that there are no bumps between each layer of eggs

Advantages

Horizontal placement device

for eggs to avoid broken eggs when eggs are turned over

Each layertier of eggs has a

fixed egg tray to truly realize

layered egg collection

The open soft egg removal

device is easy to clean and

maintain

Flexible egg pushing device
Prevent the eggs from being

caught and unable to be

discharged

Ensure smooth operation of

equipment

Ventilation fan- cooling pad environment control system

The "ventilation fan, water curtaincoolind pad, automatic environmental

control system" designed by the Longfeng professional engineer team is

based on different regional climate conditions,,breeding equipment

equipment types, breeding breedschicken type and environmental

factorsfarm environment in the field. Scientific systems design the

configuration plan in order to get the breeding effectgood harvesting you

expect

Cooling pad

The wet curtain  paper coreof cooling

pad is very good,uses high-quality

products δ150mm,Aaluminum alloy plate

frame All external  pipelines use high-

quality pipe fittings, and the wet curtain

water pump is  matched with well-known

brand products

Air inlet window

The ventilationAir inlet window

window is made of high-quality

PS engineering plastics, which is

high-quality and durable, and has

strong anti-aging ability

The temperature difference inner house is less

than 3 degrees Celsius, and it meets the ventilation

and lower the temperature requirements of each

season. In all seasons, the temperature inner

house can be controlled within a relatively

comfortable environment for chicken.

50" push-pull fan

Produced by a well-known domestic manufacturer,

with an exhaust air volume

of 35900m³/h

36" fan

Produced by a well-known domestic manufacturer,

with an exhaust air volume

of 13000m³/h

The fan is equipped with an energy-saving

motor, belt drive, and runs smoothly. The fan

blade is made of stainless steel, the surface of

the fan blade is smooth, and the outer frame is

made of HDG sheet material.

Munters AC-2000 3G

Longfeng IoT system

One-to-one connection

One IoT gateway

connects to one

environmental controller,

and independently

uploads data through the

SIM card without being

affected by other devices

Real-time data

The data is uploaded in

real time to ensure that

the alarm information is

delivered in time, and the

real-time data in the farm

can be viewed

conveniently and quickly

at any time

Lightning protection and anti-interference capability

The system adopts the standard

design of lightning protection

level for power equipment, and

has good performance against

interference from inverters and AC

contactors. It uses SIM card

wireless data upload technology

to greatly reduce the probability

of lightning strikes and ensure

safe production in the field

Security alarm

In addition to the set

threshold alarm, in case of

sudden power failure in

the shed, the IoT gateway

can also send out alarm

messages (multi-channel

alarms such as phone

calls, text messages,

network pushes, local

speakers, etc.)

Longfeng IoT system

Up to 9 alarm numbers can be set for a single building, which is easy to operate through the server setting
The alarm number can be set by means of time period, alarm method, etc. to make the alarm more accurate and timely, while avoiding unnecessary harassment
The alarm information can be edited arbitrarily through the server, making the content of the SMS easier to understand

Control system double backup, life safety is guaranteed (N2000E

series)

Built-in a set of temperature sensors powered by an independent

power supply to monitor the temperature in the house in real time

An absolute temperature can be set as a backup alarm temperature and emergency minimum ventilation control

Climate in chicken coop

● Temperature and humidity

● Air quality

● Hermeticity in the house

Equipment operating status

● Ventilation equipment

● Ventilation and cooling

equipment

● Heating and heat

preservation equipment

● Feeding and humidifying

equipment

Energy consumption and early warning

● Water consumption

● Power consumption and

alarm when the voltage and

current fluctuate greatly

● Feed consumption

When the environmental control is not ideal, it can be viewed and diagnosed remotely

Export the Excel table according to the feeding cycle for more comprehensive data analysis

It is not possible to modify

the parameters of the

environment controller

remotely, but the

modification records on site

can be viewed on the server

at any time

Operation and maintenance plans can be set for running fans, wet curtains

and other equipment with optional duration and regular intervals

Exceed the operation and maintenance time, the equipment user will be

reminded in time and the log record will be carried out

All parameter modifications to the main control computer of the

environmental control will be recorded in the server so that the data

operation can be traced

It can also access various equipment data and alarms other than the environment controller

● Electric meter ● Feeder ● Egg collector ● Feed tower weighing ● Feed line overload alarm ● Water pump overload alarm

● Other equipment data and alarms

Intelligent

precise

sensitive

reliable

Mobile terminal

Data center

Computer

It can also access data that cannot be connected to the

environment controller.E.g

◆ Electric meter

◆ Feeder

◆ Silos weighing

◆ Other equipment alarm information,etc.

Environmental indicators

parameters

Production index

parameters

Equipment operating status

Multi-channel alarm

SMS call alarm

Emergency

temperature

control

Data analysis optimization

Data analysis optimization

Data analysis optimization

Data analysis optimization

Data analysis optimization

Data analysis optimization

Remote

monitoring

Increase

collection

equipment

Equipment

maintenance
